Patient Care Monitoring System (pcms01a_hc)

Four-Digit Display with 1" High Digits and Red LEDs, Four-Digit Display with 1" High Digits, Red-Yellow-Green lamps with 2.5" x 2.5" LED Clusters, in Common Metal Enclosure for Hospital Compliance.

Specifications

Four digit LED display showing the number of minutes and seconds since the patient was last checked on.

Four digit LED display showing the number of hours and minutes that the patient has been in the room.

Green indicator indicate that the patient has recently been checked on.

Yellow indicator indicate that the patient needs to be checked on soon.

Red indicator to indicate that the patient is over due to be checked on.

User programmable times for the Green, Yellow and Red indicator lamps using an IR remote.

Two RJ45 modular connectors for RS422 serial data transmission and reception.

RJ11 modular connector for remote Start, Stop and Reset inputs.

Power connector (2.1x5.5mm).

Power requirements: 10-15VAC or 12-20VDC.

Current consumption: 500mA maximum.

Construction: Stainless steel metal enclosure with overlay having transparent red, yellow and green windows.

Mounting methods

Standard mounting fits over a single or double gang electrical box for wall mounting.

Alternate mounting is 2 key hole slots for wall mounting.

Documentation

Cutsheet
